TS-CE36-84WE2
- ES
 |
 |
| Code | TS-CE36WE2 | TS-CE48WE2 | TS-CE42WE2 |
|---|---|---|---|
| Rated Power | 36W | 42W | 48W |
| Lighting Model QTY | 2 Model | 3 Model | 4 Model |
| Lumens | 4320lm +/-5% | 5760lm +/-5% | 5040lm +/-5% |
| Beam Angle | 75° | 75° | 75° |
| Installation | Recessed/Suspended | Recessed/Suspended | Recessed/Suspended |
| Size | 595*595MM | 595*595MM | 595*595MM |
 |
 |
| Code | TS-CE36WE2 | TS-CE48WE2 | TS-CE42WE2 | TS-CE72WE2 | TS-CE84WE2 |
|---|---|---|---|---|---|
| Rated Power | 36W | 42W | 48W | 72W | 84W |
| Lighting Model QTY | 2 Model | 2 Model | 4 Model | 4 Model | 6 Model |
| Lumens | 4320lm +/-5% | 5760lm +/-5% | 5040lm +/-5% | 8640lm +/-5% | 10080lm +/-5% |
| Beam Angle | 75° | 75° | 75° | 75° | 75° |
| Size | 1195*150MM | 1195*295MM | 1195*295MM | 1195*595MM | 1195*595MM |
| Products Name | LED panels drop ceiling lighting |
|---|---|
| Body Color | Sandy White / Sandy Black |
| Shape | Square |
| Materials | Iron shell + PCB + UGR diffuser cover |
| IP Rate | IP20 |
| Anti-glare | Yes |
| UGR | <19 |
| Flicker Free | Yes |
| Installation | Surface / Suspended Type |
| Certificates | CE-EMC, CE-LVD, RoHS, FCC, C-tick |
| Working Voltage | 220-240VAC / 100-277VAC |
|---|---|
| Frequency | 50/60Hz |
| Power Factor(PF) | >0.9 |
| Driver Brand | Eaglerise/ Lifud/Philips Driver |
| Dimmable | Non-DIM / 0-10V / Dali /Pushing Dimming |
| Total Harmonic Distortion(THD) | ≤15% |
| Color Temperature | 27/30/40/45/50/60K Warm White/Neutral White/ Day White/ Cool White |
|---|---|
| Lighting Efficiency | 90-100lm/W |
| Chip Brand | Bridgelux, Epistar, Lumileds Or Other |
| Color Render Index | Ra>80 |
| SDCM | <5 |
| Anti Glare | Yes, (UGR<19) |
| Flicker Free | Yes |
| Ambient Humidity | 10%~90% |
|---|---|
| Ambient Temp. | -20 ~ 50℃ |
| Storage Temp. | -30 ~ 80℃ |
| Working Temp. | < 60℃ (Ta=25℃) |
| Life Span | >50000 Hours (LM80) |
| Warranty | 3 Years |
